Krypton
Shimano Ultegra Di2
$6,000 USD
Iridescent Charcoal, Gloss
Rainbow Grey
Find your size
All images on this page are used for illustrative purposes only. Actual bike specifications may vary depending on country and assembly options available. Please refer to the Features and Configurations section below for options available in your region.
Shimano Ultegra Di2 Components
Shimano Ultegra Di2 R8150
With lightning-fast, accurate, and reliable shifting performance, Ultegra Di2 puts riders in complete control and ensures a seamless interface between the cyclist and bike.
Vittoria Corsa N.EXT 32-622 TLR, black G2.0
Built for speed, the Corsa N.EXT Tubeless-Ready is optimized for maximum performance. It delivers aero efficiency, low rolling resistance, and confident cornering grip, combined with the durability and puncture protection that keep you pushing at race pace day after day.
Frameset
Frame
Krypton
Fork
Krypton
Headset
IST2
Integrated Cables
Yes
Storage Optimization System
Length chart
Yes
Wheels
Wheels
Scope R4.A
Tires
Vittoria Corsa N.EXT 32-622 TLR, black G2.0
Tire Clearance
Up to 40c (43mm) tire clearance
Group
Bottom Bracket
TOKEN T47 24mm
Front Derailleur
Shimano Ultegra Di2 R8150
Rear Derailleur
Shimano Ultegra Di2 R8150
Crankset
Length chart
Shimano Ultegra FC-R8100 50/34
Chain
Shimano Ultegra CN-M8100
Cassette
Shimano Ultegra CS-R8100 11/34
Brakes
Brakes
Shimano Ultegra Di2 R8170
Rotors
Shimano Ultegra RT-CL800 / F:160mm R:140mm
Shifters
Shimano Ultegra Di2 R8170
Other Components
Handlebar
Width chart
FSA Energy SCR Compact
Stem
Length chart
FSA SMR
Bar Tape
Ciclovation LEATHER TOUCH Tornado Gloss
Saddle
Repente Quasar
Seatpost
Argon 18 TDS-C
Included with bike
Toolkit
No
Geometry and fit
Geometry
XXS44-46
XS47-50
S51-53
M54-56
L57-59
XL60-62
A
Seat tube Height
cm
42.0
45.0
48.5
52.0
55.5
59.0
B
Seat tube angle
deg
75.5
74.9
74.3
73.7
73.1
72.5
C
Head Tube Angle
deg
70.6
71.5
72.3
72.3
72.3
72.8
D
Top tube length
cm
49.6
51.6
53.7
55.8
58.0
60.4
E
Chain stay length
cm
41.5
41.5
41.5
41.5
41.5
41.5
F
Wheelbase
cm
97.5
98.4
98.9
100.5
102.0
103.3
G
BB Drop
cm
8.0
8.0
7.8
7.8
7.8
7.8
H1
Head Tube Length 3D (0mm)
cm
10.6
12.3
14.2
16.4
18.6
20.8
H2
Head Tube Length 3D (25mm)
cm
13.1
14.8
16.7
18.9
21.1
23.3
I
Stand Over Height
cm
67.5
70.4
73.8
77.0
80.1
83.2
Fit (Stack and Reach)
XXS44-46
XS47-50
S51-53
M54-56
L57-59
XL60-62
J
Stack
cm
52.3
54.3
56.3
58.4
60.5
62.8
J
Stack 3D (25mm)
cm
54.7
56.7
58.7
60.8
62.9
65.2
K
Reach
cm
35.7
36.7
37.7
38.6
39.5
40.6
K
Reach 3D (25mm)
cm
34.9
35.9
37.0
37.9
38.8
39.8
Saddle Height Min
cm
59.0
62.0
65.5
69.0
72.5
76.0
Saddle Height Max
cm
74.0
77.0
80.5
84.0
87.5
91.0
Other Configurations
Subito eRoad
The performance engineering of our top road bikes - with a built-in tailwind.
Krypton
Up for any challenge: The most versatile bike in our lineup, the Krypton keeps your legs fresh over any distance and any surface.
Krypton Pro
From long rides on tarmac or cobbles to packed gravel races, whether it’s to the edge of town or around the world, the new Krypton adds speed to any surface.
